FUNDAMENTALS OF ENGINEERING (FUNDIES) FINAL EXAM 2025 QUESTIONS AND ANSWERS What do the first, second, and third numbers represent in the compartmentation number 3-76-2 - ....ANSWER ...-(3) The deck number, the third deck below the main deck. (76) The frame number, this is the 76th frame from the bow. (2)This is the position in relation to the centerline of the ship. It is on the port side. List five items or components that can be found in shaft alley: - ....ANSWER ...-1. Main Shaft 2. Remote Operating Station 3. Sterntube lube oil filter unit (Mag filter) 4. Controllable Pitch Propeller Hydraulic Tank 5. Macerator Pump Describe the purpose of piping: - ....ANSWER ...-To provide a means of carrying a fluid to and from components of a system. it completes the circuit. With regard to a ship at sea, when the bow and stern are influenced by wave peaks and the midships region by a trough, the ship is likely to ___. - ....ANSWER The designation "schedule 80 extra strong" refers to: - ....ANSWER ...-Sag ...-Piping wall thickness ....FOR STUDY PURPOSES...©️2025 ALL RIGHTS RESERVED... 1
